The new F3S is a split 5-spoke, fully forged wheel that has drastically increased tensile strength and weight reduction which exceeds even that of our already impressive Flow Form line up. The F3S is representative of our progression, innovation, and dedication to deliver you an uncompromising product thats only achievable through forging. The seasoned driver will welcome the crisper handling, faster acceleration, and improved braking that all come from a lightweight, rigid wheel. Available in 17 and 18in applications and exclusively in Satin Charcoal, each wheel includes knurled beading and a low-profile center cap.

The sleek, split-spokes of the F3S create two different window sizes one is
a larger “D” shape while the other forms a smaller, triangular shape. Both windows and spoke sides feature pronounced ball cuts to remove excess material from the front of the spokes revealing a web which translates stress around the window as it radiuses into a slightly raised drop center flange. A C-channel flange used on the wheels lip greatly increases overall rigidity. A series of precision cuts, radius, chamfers and angles were used to shed material anywhere I wasnt needed in an effort to further reduce and improve fatigue strength by reducing stress concentrations. All of this is found and confirmed using state of the art Finite Element Analysis (explained below).

Utilizing Finite Element Analysis (FEA) and advanced engineering simulation
software, we push every wheel design through countless variations of impact,
bending, and stress simulations. The processes help optimize wheel weight,
increase strength and rigidity, and reinforce high-stress areas. FEA allows us
to do hundreds of minor adjustments and simulations before we even get to
actual physical testing.

Traditional wheel designs often struggle to accommodate larger brake setups, especially on performance-oriented vehicles. Konig Forged wheels address this by utilizing size-specific concavity profiles. By strategically dishing the center section, we create ample clearance for big brake kits without compromising the wheel’s overall design. This ensures optimal braking performance without resorting to spacers, which can introduce fitment issues and affect handling.

Knurled Bead Seat

Konig forged wheels incorporate knurled bead seating, a design feature that enhances the tire-to-wheel interface. This textured surface optimizes grip and minimizes tire slippage during high-performance maneuvers, promoting precise handling and driver confidence.

Ball Cut Wheel

This spoke window design incorporates a ball-cut framed section to enhance rigidity. The frame creates a secondary load path, improving deflection resistance and load transfer. Additionally, the framed section visually separates the window into two sections within the same area, adding a dimensional aesthetic to the wheel. To minimize unsprung weight and rotational mass, lightening holes have been strategically placed throughout the design.

HERITAGE BUILT. PERFORMANCE DRIVEN.

Konig isn’t just about flashy looks. We’ve been meticulously crafting wheels for over four decades, constantly evolving our manufacturing processes to achieve the perfect balance of strength, weight, and style. When you choose Konig, you’re not just getting a wheel, you’re choosing a trusted partner with a proven track record of innovation and performance.

Quality Control

Konig wheels don’t just look good they’re built to last. Our commitment to quality control goes beyond aesthetics. We utilize advanced inspection methods and rigorous testing procedures to ensure every wheel meets the highest performance standards.

Weight 19.55 lbs.

Features:

• 4 and 5 Lug Options
• Lightweight
• Forged
• Low Offsets
• Available in 17″, 18″
• Finished in Satin Charcoal
